LEGRAND

REF. 027014 EAN. 3245060270148

Compare Μπορείτε να συγκρίνετε μόνο 4 προϊόντα, πρέπει να αφαιρέσετε 1 για να προσθέσετε αυτό

Rated permanent current Iu	40 A
Rated voltage	110-550 V
Rated short-circuit breaking capacity Icu at 400 V, 50 Hz	10 kA
Overload release current setting	40-40 A
Adjustment range short-term delayed short-circuit release	400-400 A
Adjustment range undelayed short-circuit release	400-400 A
Device construction	Built-in device fixed built-in technique
Integrated earth fault protection	No
Type of electrical connection of main circuit	Screw connection
Suitable for DIN rail (top hat rail) mounting	Yes
DIN rail (top hat rail) mounting optional	Yes

Number of auxiliary contacts as normally closed contact	1
Number of auxiliary contacts as change-over contact	1
With switched-off indicator	Yes
With integrated under voltage release	Yes
Number of poles	4
Position of connection for main current circuit	Front side
Type of control element	Toggle
Complete device with protection unit	Yes
Motor drive integrated	No
Motor drive optional	No
Degree of protection (IP)	IP30
