LEGRAND

REF. 653031 EAN. 3414971194847
Μπορείτε να συγκρίνετε μόνο 4 προϊόντα, πρέπει να αφαιρέσετε 1 για να προσθέσετε αυτό

Τεχνικά χαρακτηριστικά

Pillar shape Oval
Model Double-sided
Pre-wired No
Adjustable Yes
Height levelling 1280 mm
Column height 2770-4050 mm
Number of usable covers 2
Cover width 45 mm
Type of fastening Screwing
Place variable No
Suitable for ceiling mounting Yes
Suitable for floor mounting Yes
Cable entry Top/bottom
Through-going profile No
Material installation column Aluminium
Material quality installation column Other
Material installation column halogen free Yes
Surface protection column Anodised
Colour column Other
Material cover Aluminium
Material quality cover Other
Material cover halogen free Yes
Cover surface Anodised
Colour top cover Other
Number of partitions 1
Usable cross section 6220 mm²

2 documents
Tehnični list
F02560EN_07.pdf pdf (6.88 Mo)
Navodila za uporabo
LE10474AA-03.pdf pdf (4.26 Mo)
2 documents
Stran v katalogu
ex223001_1128.pdf pdf (0.22 Mo)
Tehnična stran v katalogu
ex223001_1130.pdf pdf (0.21 Mo)
15 documents
BIM datoteka
BIM datoteka
3D Autocad
3D_LG-653031.stp ifc (26.67 Mo)
BIM datoteka
BIM datoteka
BIM datoteka
BIM datoteka
BIM datoteka
BIM datoteka
1 document
Ooljevarstveni profil
LGRP-01503-V01.01-EN.pdf pdf (0.62 Mo)
